かえるるる(@kaeru_nantoka)です。
今回はかねてより segmentation task に取り組みたいなあ と思っていた私が、手頃なデータ落ちてないかな〜とネットサーフィンをしていたところ tarファイルで 480MB という頑張ったらローカルで云々できそうなデータセットを見つけたので、云々した物語の第一弾です。
それでは、VOC2007データセットで遊ぶ① と称して
VOC2007データセットのダウンロード ~ train_dfの作成 ~ リサイズ ~ img画像と mask画像の可視化
までを残していこうと思います。
ソースコードは ↓ です。
https://github.com/osuossu8/Play_With_VOC2007/blob/master/get_idx_name_and_mk_train_df.ipynb
ちなみに環境は、Google Colab です。
(...いいぱそこんほしい。。。)
参考 URLs
data の準備 :
https://qiita.com/tktktks10/items/0f551aea27d2f62ef708
train_dfの作成:
https://www.kaggle.com/shaojiaxin/u-net-with-simple-resnet-blocks-v2-new-loss
まず、データをここ(http://host.robots.ox.ac.uk/pascal/VOC/voc2012/#devkit)から落としてきます。
次に、tar ファイルを解凍します。
!tar -xvf "/content/drive/My Drive/VOCtrainval_06-Nov-2007.tar"
/content/ 配下に解凍されました。
[in] import os os.listdir("/content/VOCdevkit/VOC2007/") [out] ['SegmentationObject', 'Annotations', 'JPEGImages', 'ImageSets', 'SegmentationClass']
中身は ↑ のようになっています。 今回使うのは、JPEGImages(元画像), SegmentationObject(マスク画像) の二つです。
これらの配下に、 'hogehoge.jpg' や 'piyopiyo.png' といった形で画像が入っています。
最終的には、画像を pixel の numpy.array に変換して保持します。
Kaggle の塩コンペの kernel を参考に実装していきました。
img_path = "/content/VOCdevkit/VOC2007/JPEGImages" mask_path = "/content/VOCdevkit/VOC2007/SegmentationObject"
import os def get_idx_name(path): idx = os.listdir(path) idx_name = [] for i in range(len(idx)): idx_name.append(os.path.splitext(idx[i])[0]) return idx_name
まず、画像ファイル名の拡張子以外の部分を抜き出します。↑
[in] img_idx = get_idx_name("/content/VOCdevkit/VOC2007/JPEGImages") mask_idx = get_idx_name("/content/VOCdevkit/VOC2007/SegmentationObject") print(len(img_idx), img_idx[:3]) print(len(mask_idx), mask_idx[:3]) [out] 5011 ['006473', '008023', '009659'] 422 ['000661', '005859', '009950']
↑ を見ると、segmentation と対になっている元画像が422枚しかないようです。 segmentation 画像のある元画像を抜き出してみます。
[in] img_has_mask_idx = set(img_idx) & set(mask_idx) img_has_mask_idx = list(img_has_mask_idx) print(len(img_has_mask_idx), sorted(img_has_mask_idx)[:3]) print(len(mask_idx), sorted(mask_idx)[:3]) [out] 422 ['000032', '000033', '000039'] 422 ['000032', '000033', '000039']
これで使いたい画像のインデックスを集めることができました。 次にこれをもとに画像を取得して pixelの numpy.arrayにしたものを df[img], df[mask] というカラムに格納します。
まず使うライブラリを宣言して
import pandas as pd import numpy as np import matplotlib.pyplot as plt plt.style.use('seaborn-white') import seaborn as sns sns.set_style("white") %matplotlib inline from keras.preprocessing.image import array_to_img, img_to_array, load_img
train_df = pd.DataFrame() train_df["images"] = [np.array(lod_img(img_path + "/{}.jpg".format(idx))) / 255 for idx in sorted(img_has_mask_idx)[:100]] train_df["masks"] = [np.array(load_img(mask_path + "/{}.png".format(idx), color_mode="grayscale")) / 255 for idx in sorted(mask_idx)[:100]]
こんな感じになります。
[in] train_df.images[0].shape, train_df.masks[0].shape [out] ((281, 500, 3), (281, 500))
このままだと、縦横の長さが異なるので一旦縦に合わせてリサイズします。 コードは、塩コンペのカーネルにあったものを流用しています。
from skimage.transform import resize img_size_ori = train_df.images[0].shape[0] img_size_target = 101 def upsample(img):# not used if img_size_ori == img_size_target: return img return resize(img, (img_size_target, img_size_target), mode='constant', preserve_range=True) def downsample(img):# not used if img_size_ori == img_size_target: return img return resize(img, (img_size_ori, img_size_ori), mode='constant', preserve_range=True)
[in] img_resize = downsample(train_df.images[0]) msk_resize = downsample(train_df.masks[0]) img_resize.shape, msk_resize.shape [out] ((281, 281, 3), (281, 281))
揃いました。
あとは、plt.imshow()したら終わりです。お疲れ様でした。
plt.subplot(1, 2, 1) plt.imshow(img_resize) plt.subplot(1, 2, 2) plt.imshow(msk_resize)
結び
野生のデータを取得して、過去コンペのソースを頼りに欲しい形にデータを整形し、データセットを作ることができました。 train, mask 420枚づつと少々物足りないですが、augmentation などで水増しすることなどを含めて遊んでいこうと思います。
ありがとうございました。
[おまけ] 筆者が、 plt.imshow()と間違えて、plt.plot() してしまった時の写真。
おぞましすぎる。。
